A terracotta holiday villa in Arusha with a swimming pool, sun terrace and floor-to-ceiling guest glazing

Kilima Lodge

Panoramic Fixed · Lift & Slide · Glass Railings — 18 guest villas with custom glazing per unit, pool terrace.

Project
Kilima Lodge
Location
Arusha
Country
Tanzania
Building type
Hospitality / Eco-Lodge
Scope
18 guest villas with custom glazing per unit, pool terrace
Year
2025
Systems
PF-35 · LS-60
Finish
White render · anodised natural
Glass
Low-E panoramic IGU
A terracotta holiday villa in Arusha with a swimming pool, sun terrace and floor-to-ceiling guest glazing

01 / 01

An Arusha eco-lodge read as individual guest villas around a pool terrace: floor-to-ceiling glazing per unit, a lift-slide patio wall and a post-free glass balustrade along the deck. The envelope is configured per villa rather than repeated as a single module.

Materials & finishes

PF-35 · LS-60 — White render · anodised natural — Low-E panoramic IGU

The brief

A hospitality / eco-lodge in Arusha, Tanzania — 18 guest villas with custom glazing per unit, pool terrace. Frames finished white render · anodised natural, glazed with low-e panoramic igu, delivered in 2025. The scope and the frame line were fixed on one numbered window schedule before anything was cut.

The schedule pairs Panoramic Fixed Glazing with Lift & Slide Doors — different openings, one thermal-break platform, so the façade keeps a single frame line from the street. For Africa, the schedule follows SANS 10400-N / SANS 10400-XA / SANS 1263-1 / SANS 1263-2 / SANS 613 / SANS 10137 / SANS 10160-2, with the report referenced to the models on the order.

The schedule, system by system

What each line of the schedule had to carry, with the tested figures that ship with the order — read straight from the system records, not retyped for this page.

PF-35 — windows

Panoramic Fixed Glazing

A 35 mm face width that puts the view first and the frame last.

Profile system
Slim-face fixed glazing, 35 mm front face
Single pane
Up to 4,000 mm wide × 3,000 mm high
Corner solution
Frameless 45° corner glazing, structural silicone
Full system page →

LS-60 — doors

Lift & Slide Doors

The largest opening in the range. A 6-metre sliding wall that disappears at the wall.

Profile system
75 / 139 / 207 mm thermal-break aluminium, 2.0–4.0 mm wall
Maximum opening
6,000 mm single track, up to 4 leaves
Sash capacity
Up to 300 kg per leaf
Full system page →

Market, standards & delivery

Local standards

Configured for Africa: SANS 10400-N · SANS 10400-XA · SANS 1263-1 · SANS 1263-2 · SANS 613 · SANS 10137 · SANS 10160-2. The report references the models on this order — no standing certification is claimed.

Africa market line →

Shipping

  • Cape Town — typically 28–33 days at sea
  • Durban — typically 25–30 days at sea

Transit is the ocean leg; door-to-door lead time is quoted per order.

Documentation

Quotation within 24 hours, free shop drawings in 3 working days, a packing list per crate keyed to the drawing sheet, and the pre-shipment photo report as the baseline before the balance falls due.

Document library →

Project questions

What was supplied on this project?+

18 guest villas with custom glazing per unit, pool terrace, finished white render · anodised natural, glazed with low-e panoramic igu. The document pack for the order carried the numbered window schedule, the hardware and glass schedules, and the test reference for the configured models.

Which systems are on the schedule?+

PF-35 Panoramic Fixed Glazing, LS-60 Lift & Slide Doors — quoted line by line against the elevations. Every system shares one thermal-break platform, so the frame line stays consistent across the façade even where the openings differ.

Which standard applies to this project?+

Africa: Configured SA projects are tested to SANS 10400-N, with the safety, energy, assembly, installation and balustrade-load lines named on the same schedule and the report issued per order and per model; other markets follow the local regulation of record. Solar-control and laminated low-E glass are standard on the west-elevation schedule.

How long does a comparable project take?+

A complete quotation returns within 24 hours of the inquiry, the shop drawings follow free in 3 working days, and production runs 35–50 days on solar-control schedules, with the ocean leg to Cape Town typically 28–33 days.
